ELECTRA-KOOL™ MODEL 3000 INDUSTRIAL FAN
Our two biggest Electra-Kool™ models are too large for most electrical cabinets, but are ideal for cooling large DC motors. Models 2000 CFM blower & 3000 CFM blower force thousands of cubic feet of filtered air per minute into your DC motors, keeping them clean and cool. Electra-Kool™ is low-cost insurance against motor malfunction due to excessive heat. You’ll save a boat load of money in preventative maintenance costs.
ELECTRA-KOOL™ 3000 CFM BLOWER FEATURES:
- 3000 CFM of air flow (no filter).
- Recommended capacity: 600 HP DC motor
- 44.5” overall length (end filter to end motor), 25.38” deep (out from flange), 22.81” wide
- Rugged cast aluminum housing & impeller
- 13.5” circular flange that mounts easily
- Long lasting filter life due to huge surface area… 106 SQ FT
- Simple assembly: Filters require just one wingnut – great for quick cleaning
- Finger-guards installed on both the inlet and outlet for your safety
- One year manufacturing warranty – just in case.
NOTE: The image above shows an optional configuration of this blower. The standard build has the outlet flange and the terminal box on the left, as seen in this drawing. Please let us know which configuration you need when ordering!
MODEL 3000 PART NUMBERS & SPECS
| 3 Phase Part # | FILTER | Length | Width | Height | Accessories | Ship Weight |
|---|---|---|---|---|---|---|
13200 |
Metal Mesh (coarse) |
44.5″ |
25.5″ |
23″ |
Filter Mounting Hardware Only |
~250 lbs (LTL) |
13201 |
NONE |
25.5″ |
25.5″ |
23″ |
Filter Mounting Hardware Only |
~190 lbs (LTL) |
13202 |
Pleated Paper (fine) |
44.5″ |
25.5″ |
23″ |
Filter Mounting Hardware Only |
~250 lbs (LTL) |
MODEL 3000 MOTOR SPECIFICATIONS
Three Phase Only
10 HP, 3490 RPM, 215TC Frame
208-230/460V, 60Hz TEFC
Amps: 24.0 @ 208V, 23.2 @ 230V, 11.6 @ 460V
UR, CSA, & EEV Listed
MODEL 3000 FILTER SPECIFICATIONS
- Metal Mesh filter (coarse filtration, shown above)
- Rated 60% @ AC Fine Dust
- Four layers of corrugated aluminum mesh
- Long-lasting, corrosion resistant protection against coarse particulates
- PREFILTER WRAPS are provided along with Blowers with Pleated Paper filters.
- ½” thick, non-woven polyester to pick up larger particles and extend the life of the main filter
MODEL 3000 PARTS & SPARE FILTERS
| Part # | Description (sometimes seen along with P/N) | TYPE | DETAILS |
|---|---|---|---|
13215 |
3000-MM |
Metal Mesh Filter (coarse filtration) |
21.5″ height x 19.75″ OD |
10205 |
3000-MMKIT |
Metal Mesh FilterKIT™ |
Includes 3000-MM Filter, Filter End Cap, & Filter Mounting Hardware |
90002 |
3000-PP |
Pleated Paper Filter (fine filtration) |
21.5″ height x 19.75″ OD |
10092 |
3000-PPKIT |
Pleated Paper FilterKIT™ |
Includes 3000-PP Filter, Filter End Cap, & Filter Mounting Hardware |
